ICS Triplex T8403 Trusted TMR 24Vdc Digital Input Module

Product Overview

The Trusted® TMR 24 Vdc Digital Input module is designed to interface with up to 40 field input devices. It achieves fault tolerance through a Triple Modular Redundant (TMR) architecture within the module, ensuring redundancy and reliability for each of the 40 input channels.

Each field input undergoes triplication, and the input voltage is precisely measured using a sigma-delta input circuit. The measured field voltage is then compared to user-configurable threshold voltages to determine the reported field input state. Additionally, when a line-monitoring device is connected at the field switch, the module can detect open and short-circuit field cables. Line monitoring functions are independently configurable for each input channel. The triplicated voltage measurement, combined with onboard diagnostic testing, offers comprehensive fault detection and tolerance.

The module includes onboard Sequence of Events (SOE) reporting with a resolution of 1 ms. Any change of state triggers an SOE entry, and states are defined based on voltage thresholds that can be configured on a per-channel basis.

Features

40 Triple Modular Redundant (TMR) Input Channels: Each module supports up to 40 TMR input channels, ensuring redundancy and reliability.
Comprehensive Diagnostics and Self-Test: Automatic diagnostics and self-testing capabilities enhance module reliability.
Selectable Line Monitoring: Per-channel line monitoring detects open circuit and short circuit field wiring faults.
2500 V Impulse Withstand Opto/Galvanic Isolation Barrier: The module is equipped with a high-voltage impulse withstand opto/galvanic isolation barrier for added safety.
Onboard Sequence of Events (SOE) Reporting: The module provides SOE reporting with 1 ms resolution for precise event tracking.
Hot Replacement: The module can be hot-replaced online using dedicated Companion (adjacent) Slot or SmartSlot configurations, minimizing downtime during maintenance.
Front Panel Input Status LEDs: Each channel is equipped with input status LEDs on the front panel, indicating input status and field wiring faults.
Front Panel Module Status LEDs: Module health and operational mode (Active, Standby, Educated) are displayed via front panel status LEDs.
TϋV Certified IEC 61508 SIL 3: The module is TϋV certified to meet safety standards and is suitable for critical applications with a SIL 3 safety integrity level according to IEC 61508.
