Overview
The Yokogawa SDV541-S53 is a 16-channel digital output module designed for ProSafe-RS safety systems. It provides module isolation for accurate signal processing and reliable operation. This module is suitable for applications requiring precise control and safety compliance.
Technical Specifications
General Information
- Manufacturer: Yokogawa
- Model Number: SDV541-S53
- Product Type: Digital Output Module
- Number of Outputs: 16-channel, 24V DC with module isolation
Electrical Specifications
- Output Voltage: 24V DC
- Output Voltage Drop: 1V maximum
- External Power Supply Rating: 24V DC, 3.4A minimum
- Current Capacity: 3.4A total output
- Maximum Leak Current (Output Off): 1.6mA
- Maximum Load Current: 0.2A per output line (3.2A total)
- Minimum Load Current: 35mA
- Load Resistor Range: 120Ω to 685Ω
- Output Response Time: 30ms maximum
Power Consumption
- 5V DC: 300mA maximum
- 24V DC: 150mA maximum
Physical Specifications
- Dimensions: 3.2 cm x 10.6 cm x 13 cm
- Weight: 0.3 kg
Suffix Code Details
- S: Standard type
- 5: For pressure clamp terminal block or MIL cable, no explosion protection
- 3: ISA Standard G3, temperature range (-20°C to 70°C)
