Yokogawa AIP504-10 V net Coupler Unit Brand new in Stock

The Yokogawa AIP504-10 V net Coupler Unit is a device designed to connect two Vnet networks, which is Yokogawa’s proprietary network protocol used for linking various Yokogawa devices, including controllers, I/O modules, and analyzers. This coupler unit serves as a bridge between two physically separated Vnet networks or networks with different security requirements. Here are the key features and detailed specifications:

Key Features:

Connects two V net networks.
Operates in full-duplex mode.
Offers transparent operation.
Supports V net speeds of up to 100 Mbps.
Provides support for V net VLANs.
Includes V net security features such as MAC address filtering and Access Control Lists (ACLs).
Designed to be hot-swappable for easy installation and replacement.

Physical Specifications:

Dimensions: 100 x 100 x 43 mm.
Weight: 0.8 kg.
Power Supply: 100-240 VAC, 50/60 Hz.

Network Connections:

Two 100 Mbps Ethernet ports.
Supports V net versions 1.1 and 1.2.

Security Features:

MAC address filtering: Allows you to control which devices are permitted to communicate with the coupler unit based on their MAC addresses.
Access Control Lists (ACLs): Provides further control over network access by defining specific rules and policies.

Other Features:

Supports V net redundancy: Ensures network reliability by offering redundancy options.
Supports V net VLANs: Allows for the segmentation of the network into virtual LANs for better organization and security.

The AIP504-10 V net Coupler Unit is a versatile networking device that facilitates communication between Vnet networks while providing security and redundancy features. It can be a valuable component in Yokogawa’s industrial control and monitoring systems.

Download Yokogawa AIP504-10 PDF Manual：TI32S01J10-01E_022
