Woodward 9907-175 Load Sharing Module Most Favorable

Overview

The Woodward 9907-175 is a Load Sharing Module designed to enable load sharing between engines with speed controls. It integrates efficiently into power generation systems.

Technical Specifications

• Model Number: 9907-175

• Type: Load Sharing Module

• Input Voltage: 18-32 VDC

• Power Consumption: Approximately 5 W

• Phase Inputs:

  • 3-phase PT inputs (100-240 VAC line-to-line)

  • 3-phase CT inputs

• Communication: Compatible with Woodward SPM-A Synchronizer

• Operating Temperature: -40°C to +70°C (-40°F to +158°F)

Environmental Tolerance

• Shock: 40 g, 11 ms sawtooth pulse

• Vibration: 4 g, 5-2000 Hz

• Relative Humidity: 95% RH, 65°C, non-condensing

Additional Information

• Supply Voltage: 24 VDC

• Surge Protection: No PWM output surge protection

• Load Sharing Types: Isochronous & droop load-sharing

Weight

• Weight: 4.08 lbs
