Woodward 8273-128 Digital Load Sharing and Speed Control Module

Overview

The Woodward 8273-128 is a Digital Load Sharing and Speed Control Module designed to optimize turbine performance, particularly in single-valve steam turbines. It provides precise load sharing and speed control, ensuring reliable operation in industrial environments.

Key Features and Specifications

• Model Number: 8273-128

• Type: Digital Load Sharing and Speed Control Module

• Compatibility: Ideal for turbine applications, including steam turbines.

• Communication Protocols: Supports Modbus® for seamless integration with control systems.

• Configuration: Can be field-configured using Woodward’s Watch Window software.

Performance Specifications

• Operating Speed Range: 300 to 32,000 RPM.

• Power Supply: Standard industrial voltage range.

• Mounting: Can be mounted on panels or racks.

Environmental Specifications

• Operating Temperature: -40°C to +70°C (-40°F to +158°F).

• Environmental Tolerance:

  • Shock: 10 g, 1/2 sine wave for 11 ms.

  • Vibration: 1 mm peak-to-peak from 2 Hz to 13.2 Hz; 0.7 g from 13.2 Hz to 150 Hz.

  • Relative Humidity: 5% to 95% non-condensing.

Additional Information

• Weight: 8.00 lbs.

• Part Number: 8273-128.

• Category: Controls & Indicators.

• Subcategory: Temperature/Process Control.
