Woodward 5503-279 High-Density Versatile Input Module

Brand:Woodward

Model number:5503-279

Type:High-Density Versatile Input Module

Product origin:Made in USA

Dimensions:273.6 mm x 214.1 mm x 59.2 mm

Weight:1.5 kg

Certificate:CE, UL

Warranty:12 months

  • Product Details

Overview

The Woodward 5503-279 High-Density Versatile Input Module (HDVIM) is designed for industrial automation systems. This module supports a range of input types, including analog signals, thermocouples, and RTDs. It features 34 analog inputs, 24 thermocouple inputs, and 10 RTD inputs, making it suitable for a variety of industrial applications. The 5503-279 ensures reliable data acquisition and seamless integration with CPU boards using the VME bus.

Technical Specifications

  • Model Number: 5503-279

  • Type: High-Density Versatile Input Module (HDVIM)

  • Input Channels:

    • 34 analog inputs

    • 24 thermocouple inputs

    • 10 RTD inputs

    • 2 cold junction inputs

  • Input Types:

    • 4-20 mA signals

    • Thermocouples

    • RTDs (Resistance Temperature Detectors)

Isolation

  • The first 12 thermocouple/4-20 mA inputs are isolated as a group.

  • The second 12 thermocouple inputs and the first 4 RTD/4-20 mA inputs are isolated as separate groups.

Communication Interface

  • Integration with CPU boards is facilitated via the VME bus.

Power Requirements

  • The module operates within a standard industrial voltage range.

Operating Temperature

  • The module functions within a temperature range of -40°C to +70°C (-40°F to +158°F).

Features

  • Failure for 13 LED Flashes: Dual Port RAM Error.

  • LED Indicators: 2 LEDs for I/O fault and hardware fault detection.

  • Manual References: 26166V2, 26166V3, and 26167V1.

  • Potentiometers: None, as per the Woodward 26166V3 Manual.
