Schneider 140DD084300 Discrete Output Module Brand New

Overview

The 140DD084300 is a Discrete Output Module from Schneider Electric’s Modicon Quantum series. It is designed for industrial automation applications to provide reliable control of output signals. This module is ideal for managing devices such as actuators, valves, and indicators. It offers robust performance and fast response times, ensuring efficient operations in industrial control systems.

Technical Specifications

• Model Number: 140DD084300
• Manufacturer: Schneider Electric
• Type: Discrete Output Module
• Number of Outputs: 16
• Output Voltage: 10-60 VDC
• Output Current: 2 A per output, 12 A per module
• Surge Current: 7.5 A for 50 ms
• Response Time: ≤ 1 ms from state 0 to state 1, ≤ 1 ms from state 1 to state 0
• Maximum Leakage Current: 1 mA at 60 V
• Operating Temperature Range: 0°C to +60°C
• Storage Temperature Range: -40°C to +85°C
• Dimensions: 10.8 cm x 5.5 cm x 12 cm
• Weight: 1.50 lbs
