Schneider 140CPU65150C Unity processor Modicon Quantum Brand new in Stock

The Schneider 140CPU65150C stands as a top-tier automation controller with a broad array of applications. Featuring a potent 32-bit ARM Cortex-M4 processor, 1GB of RAM, and 16GB of flash storage, this controller is primed for diverse tasks. Its prowess extends to embracing digital, analog, and serial I/O, rendering it remarkably flexible and efficient.

Specifications

• Range of product: Modicon Quantum automation platform
• Product or component type: Unity processor

Complementary

• • • Clock frequency: 166 MHz
    • Number of slots: 10, 4, 2, 6, 16
    • Number of racks: 2 – local rack(s)
    • Number of distributed I/O station: 63 station(s) – 1 rack(s) – 3 Modbus Plus network(s)
    • Number of remote I/O station: 31 – 2 rack(s) per S908 remote I/O, 31 – 2 rack(s) per Ethernet Quantum remote I/O, 16 – 2 rack(s) per Ethernet X80 remote I/O
    • Discrete I/O number: 31744 inputs, 31744 outputs – remote, 8000 inputs, 8000 outputs – distributed – per network Modbus Plus, Unlimited (26 slots max) – local, Unlimited (31 drops of 28 slots max) – Ethernet remote I/O
    • Analogue I/O number: 500 inputs, 500 outputs – distributed – per network Modbus Plus, 1984 inputs,1984 outputs – S908 remote I/O, Unlimited (26 slots max) – local, Unlimited (31 drops of 28 slots max) – Ethernet remote I/O
    • Application specific I/O: Accurate time stamping, High-speed interrupt inputs, Serial link, Counter
    • Communication service: Ethernet router
    • Number of optional modules: 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max)
    • Maximum number of connections: 1 USB, 2 AS-Interface – distributed, 4 AS-Interface – remote, 6 Ethernet TCP/IP – local, 6 Modbus Plus – local, 6 Profibus DP – local, 1 Modbus (RS232/485 Modbus/ASCII)
    • Integrated connection type: 1 Modbus Plus with, 1 Ethernet TCP/IP with, 1 Modbus with, 1 USB with
    • Checks: Process control
    • Memory description: Expandable 7168 kB – program with PCMCIA card, Expandable 8 MB – file storage with PCMCIA card, Internal RAM 768 kB
    • Switch function: Key switch memory port on/off
    • Application structure: 1 cyclic/periodic master task -, 1 periodic fast task -, 128 I/O interrupt tasks -, 128 interrupt tasks -, 32 timer interrupt tasks -, 4 auxiliary tasks –
    • Number of instructions per ms: 10.28 Kinst/ms 100 % Boolean, 10.07 Kinst/ms 65 % Boolean and 35 % numerical
    • System overhead: 0.2 ms for fast task, 1 ms for master task
    • Bus current requirement: 2160 mA
    • Local signalling: 1 LED (green) for Ethernet activity (COM), 1 LED (red) for Ethernet collision
    • Electrical connection: 1 female connector, connector type: SUB-D 9 for connecting to the Modbus Plus network, 1 connector, connector type: RJ45 for connecting Ethernet network, 1 connector, connector type: RJ45 for connecting Modbus bus

Environment

• Protective treatment: Conformal coating Humiseal 1A33
• Product certifications: UL, IEC-Ex, ATEX zone 2, CE, GOST, Misc (Marine), CSA
• Standards: HazLoc

Packing Units

• Unit Type of Package 1: PCE
• Number of Units in Package 1: 1
• Package 1 Height: 11.0 cm
• Package 1 Width: 18.5 cm
• Package 1 Length: 32.5 cm
• Package 1 Weight: 1.423 kg
• Unit Type of Package 2: S03
• Number of Units in Package 2: 2
• Package 2 Height: 30.0 cm
• Package 2 Width: 30.0 cm
• Package 2 Length: 40.0 cm
• Package 2 Weight: 3.433 kg

Contractual warranty:

Warranty: 18 months

Dimensions Drawings
