Schneider 140ACO13000 Analog Output Module Brand New

Overview

The Schneider 140ACO13000 is an Analog Output Module from the Modicon Quantum series, designed for industrial automation. It ensures reliable output capabilities for various control systems.

Technical Specifications

• Model Number: 140ACO13000
• Manufacturer: Schneider Electric
• Type: Analog Output Module
• Number of Channels: 8

Output Characteristics

• Output Voltage Range:
  • 0-20 mA, 0-25 mA, 4-20 mA
• Resolution: 12 bits
• Accuracy: ±0.2% of full scale at 25°C
• Linearity:
  • ±12 µA for 4-20 mA
  • ±4 µA for 0-20 mA and 0-25 mA

Temperature and Performance

• Temperature Drift:
  • 0.004% of full scale/°C typical
  • 0.007% of full scale/°C maximum
• Operating Temperature: 0°C to +60°C

Fault and Isolation Features

• Fault Type: Open circuit for 4-20 mA
• Isolation Voltage: 1780 V for 1 minute AC

Performance and Power

• Update Time: 5 ms
• Setting Time:
  • 3.2 ms to ±0.1% of final value
  • 1.6 ms to 5% of final value
• Bus Current Requirement: 550 mA
• Power Dissipation: 5 W
• External Power Requirement: 6-30 VDC

Additional Features

• LED Indicators: Yes
• Marking: CE
• Dimensions: 273.6 mm x 214.1 mm x 59.2 mm
• Weight: 0.30 kg
