Overview
The Honeywell TK-IAH161 is an advanced analog input module designed for use with the Honeywell Experion® PKS control systems. It efficiently converts analog signals from field devices, such as sensors, transmitters, and RTDs, into digital signals. This enables the control system to process the data for effective monitoring and control. The module features 16 input channels, supporting both 4-20 mA current and 10VDC voltage signals.
Technical Specifications
- Product Name: TK-IAH161 PLC Analog Input Module
- Manufacturer: Honeywell
- Product Series: Experion® PKS C200, C300
- Part Number: TK-IAH161
- Input Types: Current (4-20 mA), Voltage, RTD
- Input Voltage Range: -10V to +10V
- Input Current Range: 4-20 mA
- Resolution: 16-bit
- Sampling Rate: Up to 1 kHz
- Isolation: 1500 V DC
- Input Impedance:
- Voltage: 100 kΩ
- Current: 250Ω
- Dimensions: 325 mm x 150 mm x 150 mm (12.8 in x 5.9 in x 5.9 in)
- Weight: 0.7 kg
- Operating Temperature Range: -40°C to +85°C
