Overview
The Honeywell LG1093AA24 is an ultraviolet (UV) flame detector designed for use in burner control units, particularly in gas turbines. It plays a vital role in flame safety systems by detecting the presence or absence of a flame using ultraviolet radiation. This information is then transmitted to the burner control unit, ensuring the safe and efficient operation of the burner in industrial and commercial heating applications.
Technical Specifications
-
Model Number: LG1093AA24
-
Type: Ultraviolet Flame Detector
-
Manufacturer: Honeywell
-
Detection Range: 1850 to 2650 angstroms (UV light)
-
Mounting Interface: 3/4 inch internal NPT
-
Cable Type: Teflon shielded cable with 1-inch external conduit thread
-
Operating Temperature Range: -40°F to +350°F
-
Window Pressure Rating: 150 psig at 400°F
-
Cable Length: 4.9 meters (16 ft) standard; other lengths available
-
Weight: 2.35 lbs
-
Application: Gas turbine flame monitoring systems
