Honeywell FC-GMLA16 16-channel analog input module

The Honeywell FC-GMLA16 is a 16-channel analog input module designed for converting 4-20 mA current signals into digital values. This smart module offers a range of valuable features, including:

Fault Detection: Capable of detecting open circuits and short circuits on each of its 16 channels.
Linearization: Can linearize input signals to compensate for non-linearities typically found in sensor outputs.
Filtering: Provides signal filtering capabilities to eliminate unwanted noise.
Calibration: Offers the option for calibration to a known reference value.

This module features a single isolated channel, making it particularly suitable for applications where the input signal originates from a hazardous area. It operates on a 24 VDC power supply with a modest current consumption of 20 mA. Its operating temperature range spans from -40 to 70°C, and it boasts an ingress protection rating of IP65. In terms of dimensions, the module measures 96 x 96 x 60 mm.

Technical Specifications:

Part Number: FC-GMLA16
Model: 16ch AI 4-20mA FTA Single ch. CC
Number of Channels: 16
Input Signal: 4-20 mA current
Fault Detection: Yes
Linearization: Yes
Filtering: Yes
Calibration: Yes
Power Supply: 24 VDC
Current Consumption: 20 mA
Temperature Range: -40 to 70°C
Ingress Protection Rating: IP65
Dimensions: 96 x 96 x 60 mm

Applications:

Process Control
Machine Monitoring
Environmental Monitoring
Safety Systems
Medical Equipment
Building Automation

Its versatility and feature-rich design make it an asset in a wide range of industrial and monitoring applications.
