The Honeywell CC-TAID01 Analog Input Module is a 16-channel module that provides differential input for the Experion PKS system. It can be used to measure a variety of process variables, including temperature, pressure, flow, and level. The module features a high level of accuracy and repeatability, making it ideal for demanding applications.
Features:
- 16 channels
- Differential input
- 4-20 mA or 0-10 V signal
- RTD and thermocouple input
- High accuracy and repeatability
- Easy to install and configure
Applications:
- Process control
- Manufacturing
- Utilities
- Oil and gas
- Pharmaceutical
- Food and beverage
- Other industrial applications
Technical Specifications:
- Number of channels: 16
- Input type: Differential
- Signal range: 4-20 mA or 0-10 V
- Input range: RTD: -200 to 600°C (-320 to 1112°F) Thermocouple: -200 to 1800°C (-320 to 3272°F)
- Accuracy: ±0.2% of reading
- Resolution: 0.1% of reading
- Repeatability: ±0.05% of reading
- Temperature range: -40 to 60°C (-40 to 140°F)
- Humidity range: 5 to 95% non-condensing
- Dimensions: 9.5 x 10 x 2.5 inches (241 x 254 x 64 mm)
- Weight: 2.2 pounds (1 kg)
- Warranty: 3 years
Benefits:
- High accuracy and repeatability
- Easy to install and configure
- Wide range of applications
- Competitive price
Conclusion:
The Honeywell CC-TAID01 Analog Input Module is a versatile and reliable module that can be used in a variety of applications. It features high accuracy and repeatability, making it ideal for demanding applications. The module is also easy to install and configure, making it a good choice for both new and experienced users.
