Honeywell CC-PDIL01 51405040-176 Digital Input Module

Overview:

The Honeywell CC-PDIL01 51405040-176 is a 16-channel digital input module that accepts 24VDC signals as discrete inputs. It is used in industrial automation systems to monitor and control a variety of devices, such as sensors, switches, and actuators.

Features:

16 channels (12 single-ended / 4 differential)
24VDC input voltage
16-bit A/D converter resolution
Common mode rejection ratio (CMRR) of 70dB
Normal mode rejection ratio (NMRR) of 19dB
Crosstalk of -60dB
Input impedance of >10MΩ
Maximum input voltage of ±30V

Technical specifications:

Dimensions: 19.1 x 18.8 x 6.5 cm
Weight: 0.4 kg
Operating temperature: -20 to 60°C
Storage temperature: -40 to 85°C
Humidity: 5 to 95% non-condensing

Honeywell CC-PDIL01 51405040-176 and 51405040-175:

Feature	CC-PDIL01 51405040-176	CC-PDIL01 51405040-175
Number of channels	16	8
Input voltage	24VDC	24VDC
A/D converter resolution	16-bit	12-bit
CMRR	70dB	60dB
NMRR	19dB	15dB
Crosstalk	-60dB	-50dB
Input impedance	>10MΩ	>1MΩ
Maximum input voltage	±30V	±24V
