Function:
The Analog Output (AO) Module provides a high-level constant current to actuators and recording/indicating devices.
Notable Features:
- Extensive self-diagnostics
- Optional redundancy
- Configurable safe-state (FAILOPT) behaviors on a per-channel basis
- Output read-back and alarm on discrepancy
- Non-incendive output
FAILOPT: The Series C AO module supports the FAILOPT parameter on a per-channel basis. Users can configure each channel to either HOLD LAST VALUE or SHED to a SAFE VALUE. The output will always go to zero (the safe state) if the IOM device electronics fail.
Open-wire Detection: This Series C IO function can detect and annunciate open field wires with a Channel Soft Failure indication.
Detail Specifications – High-Level Analog Output:
Parameter Specification
Input / Output Model:
- CC-PAOX01 – High-Level Analog Output
IOTA Models:
- CC-TAOX01 Non-Redundant 6”
- CC-TAOX11 Redundant 12”
- CC-GAOX11 Redundant 12”
- CC-GAOX21 Non-Redundant 6”
Output Type:
- 4-20 mA
Output Channels: 16
Output Characteristics:
- Output Ripple: < 100 mV peak-to-peak at power line frequency, across 250 Ω load
- Output Temperature Drift: 0.005% of Full Scale/°C
- Output Readback Accuracy: ±4% of Full Scale
- Output Current Linearity: ± 0.05% of Full Scale nominal
- Resolution: ± 0.05% of Full Scale
- Calibrated Accuracy: ± 0.35% of Full Scale (25°C) including linearity
- Directly Settable Output Current Range: 0 mA, 2.9 mA to 21.1 mA
Electrical Characteristics:
- Maximum Resistive Load (24 V supply = 22 VDC through 28 VDC): 800 ohms
- Maximum Output Compliant Voltage (24 V supply = 22 VDC through 28 VDC): 16 V
- Maximum Open Circuit Voltage: 22 V
- Response Time (DAC input code to output): Settles to within 1% of the final value within 80 ms
- Gap (0 mA) of Output to Field on Switchover: 10 ms maximum (applies to Redundancy only)
This information details the specifications and features of the High-Level Analog Output module in the Experion Series-C I/O system.
For more information, please read online or download: EP03-490-520_V10_SCIO_1_5
