The Central Part (CP) of the FSC system is connected to the I/O level via the vertical bus driver (VBD) modules, which are located in the Central Part rack. A maximum of 14 vertical bus drivers can be installed per Central Part. Each vertical bus driver can support up to 10 horizontal bus driver (HBD) modules.
The maximum distance between a vertical bus driver and any I/O rack on the vertical bus is 5 m (16.4 ft)
Vertical bus
The vertical bus flatcable connects the vertical bus drivers (VBDs,10001/1/1 or 10001/R/1) to the horizontal bus drivers (HBDs,10100/1/1 or 10100/2/1). For details on vertical buses refer to the
‘V-Buses’ data sheet：3-4-6-10-14
Specifications
- Software versions: all
- Space requirements: 4 TE, 3 HE (= 4 HP, 3U)
- Power requirements: 5 Vdc 225 mA
- Ripple content: < 50 mV p-p
