HIMA Z6012 Fan Module with Monitoring Capabilities

Overview

The HIMA Z6012 is a fan module designed for reliable cooling and system integrity. It integrates into the HIMA H51q safety system, ensuring optimal performance in demanding environments.

Technical Specifications

• Model Number: Z6012

• Type: Fan Module with Monitoring Capabilities

• Manufacturer: HIMA

• Electrical Supply Voltage: 24 V DC

• Power Consumption: Maximum 5 W

• Fuse Rating: 4 A T/slow, 5 x 20 mm

• Fan Run Monitoring: Continuously checks for operation.

• Fuse Monitoring: Detects fuse failure.

• Alarm Output: Provides a relay contact of 24 V DC, 1 A.

• Dimensions: 100 mm x 50 mm x 80 mm

• Weight: 0.2 kg

• Mounting: Integrated into the K 1412A/B central rack

• Operating Temperature: -25°C to +60°C

• Storage Temperature: -40°C to +85°C

• Humidity: 10–90% RH, non-condensing
