HIMA F2DO801 Safety Remote I/O Module High Quality

Overview

The HIMA F2DO801 is a Safety Remote I/O Module designed for safety-critical industrial applications. It is part of the HIMatrix series and ensures high reliability and safety.

Technical Specifications

• Model Number: F2DO801

• Type: Safety Remote I/O Module

• Relay Outputs: 8 relay outputs with forcibly guided contacts

• Voltage Range: 24 VDC ±15%-20%

• Relay Switching Capacity: ≤250 VAC/DC, max 3 A

• Response Time: ≥20 ms

• Communication: Supports SafeEthernet communication with integrated switch (2 x RJ-45 ports)

• Operating Temperature: 0°C to +60°C (storage: -40°C to +85°C)

• Dimensions: 207 mm (W) × 114 mm (H) × 86 mm (D)

• Weight: 1.3 kg

• Protection Rating: IP20
