GE Fanuc IC694MDL340 Discrete Output Module Brand New

The IC694MDL340 is a 120 VAC discrete output module designed for use with Emerson Automation’s PACSystem RX3i series (formerly GE Intelligent Platforms). This module provides sixteen discrete output channels, split into two groups of eight, and is ideal for controlling various automation systems.

Technical Specifications

• Rated Voltage: 120 VAC
• Output Voltage Range: 85-132 VAC
• Frequency: 47-63 Hz
• Output Current per Channel: 0.5 A
• Maximum Output Current per Group: 3 A
• Total Current Draw: 315 mA (with all outputs active)
• Isolation: Optical isolation at 250 VAC continuous; 1500 VAC for 1 minute (group-to-group isolation)
• Inrush Current: 20 A for 1 cycle
• Output Voltage Drop: 1.5 V max
• Leakage Current: 2 mA max
• On Response Time: 1 ms max
• Off Response Time: ½ cycle max
• Minimum Load Current: 50 mA
• Fuses: 2 protective fuses (3 A each)
• Operating Temperature: 0 to 60°C (32 to 140°F)
• Storage Temperature: -40 to 85°C (-40 to 185°F)
• Humidity: 5% to 95%, non-condensing
• Weight: 0.40 lbs
