GE Fanuc IC660EBD022 Genius Block I/O Module High Quality

Overview

The IC660BBD022 is a Genius Block I/O module from GE Fanuc, now under Emerson Automation. It provides 16 sourcing I/O circuits that are easily configurable for input or output. This module operates on 24V/48V DC and communicates via the Genius protocol to interface with PLCs, PACs, Bus Controllers, HMIs, and third-party devices. The IC660BBD022 is designed for industrial environments, featuring advanced diagnostics and safety measures. It allows easy configuration using a Handheld Monitor (HHM) or remotely via host controller programming software.

Technical Specifications

Part Number: IC660BBD022
Brand: GE Fanuc / Emerson Automation
Series: Genius I/O
Description: Source I/O block with 16 I/O circuits
Input Voltage: 24/48 VDC
Output Current: 2 Amperes per circuit
Operating Voltage: 18-30 VDC
Input Processing Time: 1.7 ms
Output Response Time: 1.0 ms
Input Diagnostics: Open wire, Overtemperature, Failed Switch
Output Diagnostics: Short Circuit, Overload, No Load, Failed Switch, Overtemperature
Max. Inrush Current: 10 Amperes (up to 10 ms duration)
Output Turn-on Delay: 1 millisecond
Maximum Switching Frequency: 1 per second
Heat Dissipation: 68.8 Watts (with 2 Amps load current)
Max. Ripple: 10%
Block to Block Isolation: 1500V for 1 minute
Temperature Range:
- Operating: 0°C to 60°C
- Storage: -40°C to 100°C
Humidity: 5-95%, non-condensing
Dimensions: 8.83″ x 4.42″ x 3.56″ (22.44 cm x 11.24 cm x 9.04 cm)
Weight: 2.65 lbs
