Overview
The IC200ALG630 is a versatile 7-channel thermocouple and millivolt input module from the VersaMax I/O series, formerly manufactured by GE Intelligent Platforms and now produced by Emerson Automation. This analog input module is designed to handle a wide range of industrial applications that require precise temperature measurements or integration with non-standard millivolt signals from transducers. It supports various thermocouple types (J, K, T, S, and R) and offers multiple millivolt signal ranges.
Technical Specifications
- Brand: GE Fanuc / Emerson Automation
- Series: VersaMax
- Module Type: 7-Point Thermocouple / Millivolt Input Module
- Part Number: IC200ALG630
- Resolution: 16-bit
- Compatible Thermocouples: Type J, K, T, S, R
- Millivolt Input Ranges:
- +/-19.5 mV
- +/-39 mV
- +/-78.125 mV
- +/-156.25 mV
- +/-312.5 mV
- +/-625 mV
- Power Consumption: 125 mA (from 5 VDC and 3.3 VDC backplane power)
- Accuracy at 25°C:
- Voltage measurement: +/-0.2%
- Temperature measurement (Thermocouples): +/-0.15%
- Channel Update Rate:
- 60 ms per channel @ 60 Hz
- 70 ms per channel @ 50 Hz
- Temperature Sensitivity (0-60°C): +/-0.004% of reading, +/-1.5 µV per °C
- Operating Temperature Range: 0°C to 60°C
- Backplane Current Consumption: 125 mA (5 VDC) and 125 mA (3.3 VDC)
- Diagnostics:
- Open thermocouple detection
- Over/under-range conditions
- High/low alarms
- Thermistor error detection
- Isolation Ratings:
- Optical isolation for user inputs
- Frame-to-ground isolation: 250 VAC continuous, 1500 VAC for 1 minute
- Status LED Indicators:
- OK LED: Green for active backplane power, amber for faults
- Dimensions: 4.3 in (W) x 2.63 in (H) x 1.95 in (D)
- Weight: 0.35 lbs
-
Cable Connection: Uses shielded twisted pair cables for signal input
