GE Fanuc IC200ALG331-BA 4-Channel Isolated Analog Output Module

Overview

The GE Fanuc IC200ALG331-BA is a versatile analog output module designed to provide reliable and accurate signal control in industrial automation systems. It offers four isolated output channels, with the flexibility to configure each channel for either 4-20 mA current or ±10 VDC voltage output. This module ensures high performance, diagnostic capabilities, and easy software configuration.

Technical Specifications

Output Channels:
- 4 isolated output channels.
- Configurable for 4-20 mA or ±10 VDC output.
Resolution:
- 16-bit converter for high precision.
Output Signal Range:
- Current Mode: 4-20 mA.
- Voltage Mode: ±10 VDC.
Update Rate:
- Maximum of 7 ms.
Accuracy:
- ±0.1% of full scale at 25°C.
Current Consumption:
- 100 mA maximum plus load currents.
External Supply Voltage:
- 18-30 VDC, including ripple.

Isolation & Protection

Input to Logic Isolation:
- 250 V AC continuous.
Input to Ground Isolation:
- 1500 V AC for 60 seconds.
Channel-to-Channel Isolation:
- 250 V AC continuous, 1500 V AC for 1 minute.

Environmental Conditions

Operating Temperature:
- Typically 0 to 60°C.
Storage Temperature:
- Typically -40 to 85°C.
Humidity:
- 5% to 95%, non-condensing.

Features

Software Configurable:
- No need for jumpers or switches.
Diagnostic Capabilities:
- High/low limits, over/underrange, open wire detection, loss of field power supply, and memory faults.
LED Indicators:
- FLD PWR LED: Indicates field power status.
- OK LED: Confirms the module’s proper operation.
