EPRO CON021+PR6424/010-110 Eddy Current Sensor System

Overview

The EPRO CON021 + PR6424/010-110 system is designed for high-precision monitoring in critical machinery. It offers reliable displacement, vibration, and shaft position measurements for turbines, compressors, and pumps. This system ensures accuracy even in challenging environments.

CON021 Eddy Current Signal Converter

• Frequency Range: 0 to 20,000 Hz.

• Rise Time: <15 μs.

• Power Supply Voltage: -23V to -32V DC.

• Output Voltage Range: -4V to -20V DC.

• Operating Temperature: -30°C to +100°C.

• Protection Class: IP20.

• Certifications: CE, ATEX, IECEx, CSA.

PR6424/010-110 Eddy Current Sensor

• Measurement Range: ±2.0 mm.

• Static Range: ±2.0 mm.

• Dynamic Range: 0 to 1,000 μm.

• Linearity Error: ≤ ±1.5%.

• Air Gap: Approximately 2.7 mm.

• Operating Temperature: -20°C to +65°C.

• Certifications: Compliant with industrial safety standards.
