Emerson KJ3224X1-BK1 S-Series Thermocouple/mV Input Card

Overview

The Emerson KJ3224X1-BK1 is designed for industrial automation, providing precise thermocouple and millivolt signal monitoring. It is built to withstand hazardous environments and extreme conditions.

Technical Specifications

• Model Number: KJ3224X1-BK1

• Type: Thermocouple/millivolt (mV) input card

• Manufacturer: Emerson

• Input Channels: 8 isolated channels

• Input Signal Type: Thermocouple and mV signals

• Power Supply: 12 VDC at 210 mA

• Bus Power Requirement: 12 VDC at 210 mA

Environmental Specifications

• Operating Temperature: -40 °C to +70 °C

• Shock Resistance: 10 g, half-sine wave, duration 11 ms

• Vibration Tolerance:

  • 1 mm peak-to-peak (2 to 13.2 Hz)

  • 0.7 g (13.2 to 150 Hz)

• Humidity Range: 5% to 95%, non-condensing

• Airborne Contaminant Level: ISA-S71.04 –1985, Class G3

• Terminal Block Key Position: C1
