Overview:
The Bently Nevada 76683-50 is a proximity sensor that utilizes eddy currents to detect the presence or absence of nearby ferrous metal objects. It operates as a non-contact sensor, making it ideal for situations where direct mounting on the object is challenging or impractical.
Key Features:
- Non-contact sensor: Does not require physical contact with the target.
- Two-wire DC operation: Simplifies installation and integration.
- Nominal range: 0.25 inches (6.35 mm).
- Detection capability: Can detect targets as small as 0.125 inches (3.18 mm) in diameter.
- Output current: 100 mA, ensuring reliable signal transmission.
- Protection features: Equipped with reverse polarity and short circuit protection.
- Rugged construction: Stainless steel housing rated IP67 for dust and water resistance.
- Temperature range: Operates in temperatures from -40 to 180 degrees Fahrenheit (-40 to 82 degrees Celsius).
Applications:
- Machine monitoring: Monitoring vibration in rotating machinery to detect faults and prevent breakdowns.
- Conveyor belt monitoring: Detecting the presence or absence of material on conveyor belts.
- Door and gate monitoring: Detecting the opening and closing of doors and gates.
- Part presence detection: Ensuring the presence or absence of parts in a production line.
Specifications:
- Sensor type: Eddy current.
- Target material: Ferrous metals.
- Nominal range: 0.25 inches (6.35 mm).
- Minimum detectable target size: 0.125 inches (3.18 mm).
- Output current: 100 mA.
- Operating voltage: 18 to 24 volts DC.
- Reverse polarity protection: Yes.
- Short circuit protection: Yes.
- Housing material: Stainless steel.
- IP rating: IP67.
- Operating temperature range: -40 to 180 degrees Fahrenheit (-40 to 82 degrees Celsius).
