Overview
The Bently Nevada 3500/15 114M5329-01 High Voltage DC Power Supply is designed to provide reliable and continuous power to Bently Nevada 3500 monitoring systems. It is a half-height module that fits into designated slots on the left side of the 3500 rack, which can accommodate up to two power supplies. These supplies can be a combination of AC and DC, offering flexibility in power configuration. This power supply ensures high uptime and is ideal for industries such as power generation, oil and gas, petrochemicals, and manufacturing.
Technical Specifications
- Input Voltage:
- High Voltage DC: 88 to 140 Vdc
- Universal AC: 110 to 220 Vac nominal, 85 to 264 Vac rms, 120 to 373 Vac peak
- Low Voltage DC: 20 to 30 Vdc
- Operating Temperature:
- -22 to 150°F (-30 to 65°C)
- Full Rack Current Draw:
- Universal: 2.8 A rms (maximum)
- Protection:
- Under-voltage: Does not damage the power supply or PIM
- Over-voltage: Causes the fuse to open on the PIM
- Hot-Swappable:
- Modules can be inserted or removed without disrupting rack operation if a second power supply is installed.
- Redundant Power:
- When two power supplies are installed, the lower slot is the primary, and the upper slot serves as the backup.
- LED Indicator:
- Provides a visual indication of power supply status.
- Compatibility:
- Works with both High Voltage DC and Low Voltage DC Power Supply Input Modules (PIMs).
- Power Supply Module:
- Height: 120.7 mm (4.75 in)
- Width: 50.8 mm (2.0 in)
- Depth: 251.5 mm (9.9 in)
- Weight: 1.39 kg (3.06 lb)
