Overview
The Bently Nevada 330101-085-00-00 is part of the 3300 XL series, designed for vibration and position monitoring on fluid-film bearing machines. This 8 mm proximity probe, with a 3/8-24 UNF thread and no armor, integrates with a 3300 XL Proximitor sensor and extension cable. The system is widely used for keyphasor, speed measurements, and precise monitoring of machine conditions.
Technical Specifications
General Specifications
- Model: 330101-085-00-00 8 mm proximity probe.
- Thread: 3/8-24 UNF thread (085).
- Armor: No armor (00-00).
- Temperature Range: +18°C to +27°C (+64°F to +80°F).
- Altitude: Maximum 2000 meters.
- Target Material: AISI 4140 steel target.
- Gap: Probe gapped at 1.27 mm (50 mils).
Electrical Specifications
- Proximitor Sensor Input: Compatible with 3300-series 5 mm or 3300 XL 8 mm proximity probes and extension cables.
- Power Supply:
- Requires -17.5 Vdc to -26 Vdc, with a 10 kΩ load.
- Maximum current consumption: 12 mA.
- Operation at voltages above -23.5 Vdc reduces linear range.
- Output Sensitivity: Less than 2 mV change in output voltage per volt change in input voltage.
- Output Resistance: 50 Ω.
Performance Characteristics
- System Accuracy: Applies when using 3300 XL 8 mm components calibrated to an AISI 4140 steel target.
- Interchangeability: Valid only within systems calibrated to the AISI 4140 steel target.
