Allen Bradley PLX31-EIP-MBS I Prosoft Communication Module

The Allen Bradley PLX31-EIP-MBS I Prosoft Communication Module is a versatile device that allows communication between Modbus serial devices and Ethernet/IP-based devices. This module is designed to seamlessly integrate with Allen Bradley programmable logic controllers (PLCs) and other automation equipment.

Features:

• Supports Modbus RTU, Modbus ASCII, Modbus TCP/IP, and EtherNet/IP protocols.
• Can be configured through web-based configuration tool or included software.
• Offers up to 16 Ethernet/IP connections and up to 32 Modbus serial connections.
• LED indicators for easy status monitoring.

Applications:

• Allows integration of Modbus devices with Allen Bradley PLCs and other automation equipment.
• Ideal for industrial environments with mixed communication protocols.
• Can be used in a variety of industries including oil and gas, manufacturing, and water treatment.

Technical Specifications:

• Power Input: 24 VDC (supplied by user)
• Max Power Consumption: 4 W
• Operating Temperature Range: -40 to 70°C (-40 to 158°F)
• Storage Temperature Range: -40 to 85°C (-40 to 185°F)
• Humidity: 5% to 95% RH, non-condensing
• Dimensions (H x W x D): 5.02 x 1.68 x 4.23 in (127.5 x 42.7 x 107.4 mm)
• Weight: 12.3 oz (0.35 kg)
• Protocol Support: Modbus RTU, Modbus ASCII, Modbus TCP/IP, EtherNet/IP
• Number of Connections: 16 TCP/IP, 32 Modbus Serial
• Data Rate: 10/100 Mbps
• Mounting: DIN rail or panel mount

Benefits:

• Provides a cost-effective solution for integrating Modbus devices with Ethernet/IP networks.
• Saves time and effort by eliminating the need for separate gateways and converters.
• Offers easy configuration and monitoring through web-based interface or software.

In summary, the Allen Bradley PLX31-EIP-MBS I Prosoft Communication Module is a reliable and efficient solution for integrating Modbus devices with Ethernet/IP networks. Its versatile protocol support, easy configuration, and cost-effectiveness make it an ideal choice for industrial applications.

Q: What is the Allen Bradley PLX31-EIP-MBS Prosoft Communication Module used for?

A: The PLX31-EIP-MBS module is used to provide Ethernet/IP connectivity to Modbus devices.

Q: What is the power supply requirement for the PLX31-EIP-MBS module?

A: The module requires a 24VDC power supply.

Q: What communication protocol does the PLX31-EIP-MBS module support?

A: The module supports Ethernet/IP to Modbus communication protocol.

Q: How many ports does the PLX31-EIP-MBS module have?

A: The module has one RJ45 port.

Q: What are the supported Modbus function codes for the PLX31-EIP-MBS module?

A: The module supports Modbus function codes 1, 2, 3, 4, 5, 6, 15, and 16.

Q: What is the maximum number of Modbus/TCP connections supported by the PLX31-EIP-MBS module?

A: The module supports a maximum of 16 Modbus/TCP connections.

Q: What is the isolation voltage of the PLX31-EIP-MBS module?

A: The module has an isolation voltage of 1500 VAC.

Q: What is the operating temperature range of the PLX31-EIP-MBS module?

A: The module can operate in temperatures ranging from -40°C to 70°C (-40°F to 158°F).

Q: What is the storage temperature range of the PLX31-EIP-MBS module?

A: The module can be stored in temperatures ranging from -40°C to 85°C (-40°F to 185°F).

Q: What is the communication rate of the PLX31-EIP-MBS module?

A: The module supports a communication rate of 10/100 Mbps.

Q: What is the weight and dimensions of the PLX31-EIP-MBS module?

A: The module weighs 7.05 oz (200 g) and has dimensions of 4.80 x 2.94 x 1.24 in (122 x 75 x 32 mm).
