Allen Bradley 1764-24BWA Base Unit Most Favorable

Overview of the Allen Bradley 1764-24BWA

The Allen Bradley 1764-24BWA is a MicroLogix 1500 base unit. It belongs to the Bulletin 1764 product family. This unit provides flexible, compact, and powerful control for industrial automation systems.

Technical Specifications

• Model Number: 1764-24BWA

• Manufacturer: Rockwell Automation (Allen-Bradley)

• Series: MicroLogix 1500

• Product Type: Programmable Controller Base Unit

• Line Power Supply: 85–265V AC, 47–63 Hz

• Power Consumption: 88 VA

• Number of I/O Points: 24 total (12 inputs, 12 outputs)

• Input Voltage: 24V DC, Sink/Source

• Output Type: Relay

• Output Voltage Range: 24–125V DC / 120–240V AC

• High-Speed Inputs: 4 channels

• Max Expanded I/O: 512 points

• Operating Frequency: 0 to 20 kHz

• Operating Temperature: 0°C to +55°C (32°F to 131°F)

• Storage Temperature: -40°C to +85°C (-40°F to 185°F)

• Mounting Style: DIN Rail (Horizontal)

• Dimensions: 5.43 x 6.62 x 3.43 inches

• Weight: 2.00 lbs

• Terminal Type: Screw Terminals
