Overview
The Allen-Bradley 1756-L63XT is a high-performance ControlLogix processor module designed by Rockwell Automation. It features enhanced memory capabilities and supports a wide range of I/O points, making it ideal for demanding industrial automation systems. Built for extreme environmental conditions, the 1756-L63XT offers robust temperature resistance, high reliability, and extensive communication options. It is engineered to operate seamlessly in harsh industrial settings, ensuring continuous performance even in challenging conditions.
Technical Specifications
- Manufacturer: Rockwell Automation
- Brand: Allen-Bradley
- Part Number: 1756-L63XT
- Series: ControlLogix
- Module Type: Processor Module
Memory and I/O
- I/O Memory: 478 Kilobytes
- User Memory: 8 MB
- Maximum I/O: 128,000
- Maximum Analog I/O: 4,000
- Maximum Digital I/O: 128,000
Power and Current
- Current Draw (5.1 VDC): 1200 milliamps
- Current Draw (24 VDC): 14 milliamps
- Power Dissipation: 3.5 Watts
- Thermal Dissipation: 11.9 BTU per hour
- Isolation Voltage: 30 Volts Continuous
Temperature Ranges
- Operating Temperature: -25°C to 70°C
- Storage Temperature: -40°C to 85°C
- Maximum Surrounding Air Temperature: 70°C
- With FLEX I/O-XT: -20°C to 70°C
Communication Options
- Ports: One RS-232 serial built-in communication port
- Protocols: ControlNet, DeviceNet, Remote I/O, SynchLink, EtherNet/IP, Data Highway Plus
- Additional Communication: Modbus, ASCII, DF1 radio modem
Capabilities
- Controller Tasks: Three event tasks, 32 tasks, 100 programs per task
- Maximum Controller Connections: 250
- Redundancy: Supported on the same ControlNet network
Durability
- Vibration: 2 g at 10 to 500 Hz
- Operating Shock: 30 g
- Non-operating Shock: 50 g
- Humidity: 5% to 95% (non-condensing)
Physical
- Weight: 1.19 lbs
- Display: LED indicators
