ABB TU818V1 3BSE069209R1 Compact Module Termination Unit In Stock

General Information

Product ID: 3BSE069209R1
ABB Type Designation: TU818V1
Catalog Description: TU818V1 Compact MTU, 50V

• Article Number: 3BSE069209R1

• Type: Compact

• Connection: Terminal block

• Channels: 32

• Voltage: 50 V

• Mounting: Both directions

Mounting Detail

• Horizontal: 55 ºC (131 °F)

• Vertical: 40 ºC (104 °F)

Use with I/O Modules

• AI: AI810, AI815, AI835A, AI843, AI845

• DI: DI810, DI811, DI818, DI830, DI831, DI840, DI880, DI885

• DO: DO818, DP840

Process Connections

• 40 pole screw terminal

• Single/Redundant I/O: Single

Detailed Data

• Maximum Current per I/O Channel: 2.5 A

• Maximum Current Process Connection:

  • L1+ max: 8 A

  • L2+ max: 8 A

• Acceptable Wire Sizes:

  • Solid: 0.5 – 2.5 mm²

  • Stranded: 0.5 – 1.5 mm²

• Dielectric Test Voltage: 500 V a.c.

Environment and Certification

• CE Mark: Yes

• Electrical Safety: EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201

• Hazardous Location: ATEX Zone 2

• Marine Certification: ABS, BV, DNV-GL, LR

• Temperature:

  • Operating: 0 to +55 °C (+32 to +131 °F), approvals for +5 to +55 °C

  • Storage: -40 to +70 °C (-40 to +158 °F)

• Pollution Degree: Degree 2, IEC 60664-1

• Corrosion Protection: ISA-S71.04: G3

• Relative Humidity: 5 to 95 %, non-condensing

• Max Ambient Temperature: 55 °C (131 °F), for vertical mounting 40 °C (104 °F)

• Protection Class: IP20 according to IEC 60529

• Mechanical Operating Conditions: IEC/EN 61131-2

• EMC: EN 61000-6-4, EN 61000-6-2

• Overvoltage Categories: IEC/EN 60664-1, EN 50178

• Equipment Class: Class I according to IEC 61140 (earth protected)

• RoHS Compliance: EN 50581:2012

• WEEE Compliance: DIRECTIVE/2012/19/EU

Dimensions

• Product Net Depth / Length: 64 mm

• Product Net Height: 170 mm

• Product Net Width: 58.5 mm

• Product Net Weight: 0.26 kg
