Overview
The SPA-ZC 400EM connects REF 541/3/5, REM 543/5, or RET 541/3/5 devices to the IEC 61850-8-1 Station bus. IEC 61850 is the new standard for substation communication. It supports substation automation functions and the engineering process.
The SPA-ZC 400 uses GOOSE messaging for fast communication between Intelligent Electronic Devices (IEDs). This allows devices to share interlocking and blocking information. Additionally, it enables Ethernet access to an IED using SPA over TCP/IP and Modbus over TCP/IP.
Key Features
The SPA-ZC 400 allows for dual-port communication with fibre-optic SPA and LON® connections. The device’s installation and commissioning details are in Chapter 5 and Chapter 6 of the manual.
Before use, understand the communication properties of the connected IED. The IED manual provides the necessary information for configuration.
Dimensions and Weight
- Dimensions: 195 mm x 50 mm x 26 mm
- Weight: 130 g
Environmental Tests and Conditions
- Service Temperature Range: -10 to +55°C (continuous)
- Transport and Storage Temperature: -40 to +85°C (IEC 60068-2-48)
Test Standards:
- Dry Heat: IEC 60068-2-2
- Dry Cold: IEC 60068-2-1
Electromagnetic Compatibility Tests
The SPA-ZC 400 meets various EMC immunity and emission requirements.
Immunity Tests:
- Burst Disturbance: Class III, 1 MHz (IEC 60255-22-1)
- Electrostatic Discharge: 6 kV (contact), 8 kV (air) (IEC 61000-4-2)
- Radio Frequency Interference:
- Conducted, common mode: 10 V (rms), 150 kHz to 80 MHz
- Radiated, amplitude-modulated: 10 V/m, 80 MHz to 2.7 GHz
- Fast Transient Disturbance: 4 kV (IEC 60255-22-4, IEC 61000-4-4)
Surge Immunity:
- Power Supply: 4 kV (line-to-earth), 2 kV (line-to-line) (IEC 60255-22-5)
Electromagnetic Emission Tests
- Conducted RF Emission: EN 55011, Class A
- Radiated RF Emission: EN 55011, Class A (IEC 60255-25)
Compliance: CE, EMC directive 2004/108/EC, LV directive 2006/95/EC
Mechanical Tests
- Vibration: IEC 60255-21-1, Class I
- Shock and Bump: IEC 60255-21-2, Class I
Power Consumption
- Running: 340 mA
- Startup: 430 mA
RoHS Compliance
The SPA-ZC 400 complies with RoHS directive 2002/95/EC.
