Overview
The RET650 Transformer Protection Relay is part of ABB’s Relion® 650 series. It is designed to provide advanced protection, control, measurement, and supervision for power transformers in both industrial and utility power systems.
Technical Specifications
-
Model Number: RET650
-
Type: Transformer Protection Relay
-
Protection Functions:
-
Differential protection for two- and three-winding transformers
-
Overcurrent protection
-
Voltage protection
-
Frequency protection
-
Thermal overload protection
-
-
Communication Protocols:
-
IEC 61850 Editions 1 and 2
-
Modbus
-
DNP3
-
IEC 60870-5-103
-
-
Inputs/Outputs: Configurable analog and digital inputs/outputs for flexible use
-
Display: Large graphical display with customizable single-line diagrams (SLDs)
-
Operating Temperature: -25°C to +55°C (-13°F to +131°F)
