Overview
The ABB NKTU01-L6 is a termination unit cable designed for stable connectivity between I/O modules and termination units in industrial automation systems. It ensures reliable signal transmission and high performance in demanding environments.
Technical Specifications
-
Model Number: NKTU01-L6
-
Type: Termination Unit Cable
-
Length: 6 feet (1.83 meters)
-
Insulation Material: PVC (Polyvinyl Chloride), ensuring durability and electrical safety
-
Supported Signals: RS-232-C and RS-485 serial communication
-
Voltage Rating: Suitable for low-voltage industrial applications
-
Applications: Used to connect I/O modules to termination units in ABB’s Bailey Infi 90 distributed control systems
-
Function: Links I/O modules to termination units for efficient signal transmission
-
Serial Communication: Supports RS-232-C up to 38.4 kilobaud
-
Station Link Capacity: Connects up to 64 IISAC01 stations at 40 kilobaud or 8 at 5 kilobaud
-
Signal Conversion: Converts RS-485 to RS-232-C via the termination unit
-
Operating Temperature: -20°C to 80°C
-
Conductor Material: High-quality copper ensures signal integrity
-
Voltage Rating: 300V maximum
-
Weight: 0.24 kg
-
Connector Type: Standard D-type connectors
