General Information
- Article number: 3BSE008514R1
- Type: Digital Output
- Signal Specification: 230 V a.c. / d.c. (5 – 250 V a.c./d.c.), 3 A
- Number of Channels: 8
- Signal Type: Relay (NO)
- HART: No
- SOE: No
- Redundancy: No
- High Integrity: No
- Intrinsic Safety: No
- Mechanics: S800
Detailed Data
- Isolation: Individually isolated, channel-to-channel and to circuit common
- Current Limiting: Can be current limited by the MTU
- Maximum Field Cable Length: 600 meters (656 yards)
- Event Recording Accuracy: -0 ms / +1.3 ms
- Rated Insulation Voltage: 250 V
- Dielectric Test Voltage: 2000 V a.c.
- Power Dissipation: Typ. 2.9 W
- Current Consumption:
- +5 V Modulebus: 60 mA
- +24 V Modulebus: 140 mA
- +24 V External: 0
Diagnostics
- Front LED’s: F(ault), R(un), W(arning), O(SP), Channel 1-8 Status
- Supervision: 24/12 V Relay power converter monitor
- Status Indication of Supervision: Module Error, Module Warning, Channel Error
Environment and Certification
- CE Mark: Yes
- Electrical Safety: EN 61010-1, UL 61010-1, EN 61010-2-201, UL 61010-2-201
- Hazardous Location: –
- Marine Certification: ABS, BV, DNV, LR
- Temperature, Operating: 0 to +55 °C (+32 to +131 °F), approvals are issued for +5 to +55 °C
- Temperature, Storage: -40 to +70 °C (-40 to +158 °F)
- Pollution Degree: Degree 2, IEC 60664-1
- Corrosion Protection: ISA-S71.04: G3
- Relative Humidity: 5 to 95 %, non-condensing
- Max Ambient Temperature: 55 °C (131 °F), for vertical mounting in compact MTU 40 °C (104 °F)
- Protection Class: IP20 according to IEC 60529
- Mechanical Operating Conditions: IEC/EN 61131-2
- EMC: EN 61000-6-4, EN 61000-6-2
- Overvoltage Categories: IEC/EN 60664-1, EN 50178
- Equipment Class: Class I according to IEC 61140 (earth protected)
- RoHS Compliance: DIRECTIVE/2011/65/EN (EN 50581:2012)
- WEEE Compliance: DIRECTIVE/2012/19/EU
Compatibility
- Use with MTU: TU811, TU813, TU831, TU836, TU837, TU851
- Keying Code: AD
Dimensions
- Width: 45 mm (1.77”)
- Depth: 102 mm (4.01”), 111 mm (4.37”) including connector
- Height: 119 mm (4.7”)
- Weight: 0.23 kg (0.5 lbs)
