ABB AI835A 3BSE051306R1 Analog Input Module In Stock

Overview

The ABB 3BSE051306R1 is an analog input module designed for use with ABB’s S800 series automation systems. It features an 8-channel input, designed for a range of thermocouple (TC) types.

General Information

• Article Number: 3BSE051306R1
• Type: Analog Input
• Signal Specification: -30 to 75 mV linear; supports TC types B, C, D, E, J, K, L, N, R, S, T, and U
• Number of Channels: 8
• Signal Type: See S800 Modules and Termination Units (3BSE020924)
• HART: No
• SOE: No
• Redundancy: No
• High Integrity: No
• Intrinsic Safety: No
• Mechanics: S800

Detailed Data

• Resolution: 15 bits
• Input Impedance: >1 MΩ
• Isolation: Groupwise isolated from ground
• Error: Max. 0.1%
• Temperature Drift: Typ. 5 ppm/°C, Max. 7 ppm/°C
• Update Cycle Time:
  • 280 + 80 * (number of active channels) ms at 50 Hz
  • 250 + 70 * (number of active channels) ms at 60 Hz
• Maximum Field Cable Length: 600 meters (656 yards)
• CMRR (50/60 Hz): 120 dB
• NMRR (50/60 Hz): > 60 dB
• Rated Insulation Voltage: 50 V
• Dielectric Test Voltage: 500 V a.c.
• Power Dissipation: 1.6 W
• Current Consumption:
  • +5 V Modulebus: 75 mA
  • +24 V Modulebus: 50 mA
  • +24 V External: 0 mA

Diagnostics

• Front LEDs: F(ault), R(un), W(arning)
• Supervision:
  • Module error: reference channels, low power supply
  • Channel error: open-circuit
  • CJ-channel (Ch. 8): < -40 °C (-40°F) or > 100 °C (212°F)
• Status Indication of Supervision: Module Error, Module Warning, Channel Error (8)

Environment and Certification

• CE Mark: Yes
• Electrical Safety:
  • EN 61010-1, UL 61010-1
  • EN 61010-2-201, UL 61010-2-201
• Hazardous Location:
  • C1 Div 2 cULus, C1 Zone 2 cULus, ATEX Zone 2
• Marine Certification: ABS, BV, DNV, LR
• Operating Temperature: 0 to +55 °C (+32 to +131 °F), approvals for +5 to +55 °C
• Storage Temperature: -40 to +70 °C (-40 to +158 °F)
• Pollution Degree: Degree 2, IEC 60664-1
• Corrosion Protection: ISA-S71.04: G3
• Relative Humidity: 5 to 95 %, non-condensing
• Max Ambient Temperature: 55 °C (131 °F); vertical mounting in compact MTU 40 °C (104 °F)
• Protection Class: IP20 (IEC 60529)
• Mechanical Operating Conditions: IEC/EN 61131-2
• EMC: EN 61000-6-4, EN 61000-6-2
• Overvoltage Categories: IEC/EN 60664-1, EN 50178
• Equipment Class: Class I (IEC 61140)
• RoHS Compliance: DIRECTIVE/2011/65/EU (EN 50581:2012)
• WEEE Compliance: DIRECTIVE/2012/19/EU

Compatibility

• Use with MTU: TU810, TU812, TU814, TU818, TU830, TU833
• Keying Code: BA

Dimensions

• Width: 45 mm (1.77”)
• Depth: 102 mm (4.01”), 111 mm (4.37”) with connector
• Height: 119 mm (4.7”)
• Weight: 0.22 kg (0.49 lbs.)
