ABB 3BHE009681R0101 5SGY3545L0009 3BHB013085R0001 IGCT Module

Overview

The ABB 3BHE009681R0101 5SGY3545L0009 3BHB013085R0001 is an Integrated Gate Commutated Thyristor (IGCT) module, designed for high-power and high-voltage applications in industrial systems. It merges the benefits of both thyristors and transistors, offering efficient switching and reliable performance.

Technical Specifications

• Model Number: 3BHE009681R0101 5SGY3545L0009 3BHB013085R0001

• Type: IGCT Module

• Rated Voltage: High voltage for industrial applications

• Voltage Rating: 1700V

• Current Rating: 1150A

• Switching Frequency: Up to 60 kHz

• Operating Temperature Range: -40°C to +125°C

• Case Dimensions: 200 x 100 x 50 mm

• Weight: 1.5 kg
