ABB 07AC91 GJR5252300R0101 Analog Input/Output Module

Overview

The ABB 07AC91 GJR5252300R0101 is an Analog Input/Output Module designed for the Advant Controller 31 system. It provides reliable signal processing and integrates seamlessly into industrial automation systems.

Technical Specifications

• Model Number: 07AC91 GJR5252300R0101

• Type: Analog Input/Output Module

• Input Channels: 8 channels, configurable for ±10 V or 0–20 mA signals

• Output Channels: 8 channels, configurable for ±10 V or 0–20 mA signals

• Resolution: 12-bit for precise signal representation

• Operating Voltage: 24 V DC

• System Bus: CS31 system bus connection

• Power Supply: 24 V DC

Performance Characteristics

• Analog Input Range: -10 V to +10 V

• Analog Input Resolution: 12 bits

• Analog Output Range: -10 V to +10 V

• Analog Output Resolution: 12 bits

• Input/Output Impedance: 2 kΩ

• Accuracy: ±0.1%

• Non-linearity: ±0.2%

• Update Rate: 250 ms

Environmental Conditions

• Operating Temperature Range: -20°C to +60°C

• Storage Temperature Range: -40°C to +80°C

• Humidity: 0% to 95% RH (non-condensing)

• Vibration: 0.5 g RMS, 10 Hz to 500 Hz

• Shock: 5 g, 11 ms half-sine pulse

Physical Specifications

• Dimensions (WxHxD): 120 x 80 x 35 mm

• Weight: 0.81 kg
